Main Features
Output frequency: 80/160/200MHz
Sampling rate: 1.2 GSa/s
Vertical resolution: 16-bit
Arbitrary waveform length: Up to 40 Mpts/ch
Supports dual pulse output function
The SDG3000X series dual-channel function/arbitrary
waveform generator has a maximum bandwidth of
200MHz, an excellent sampling system specifications of
1.2 GSa/s sampling rate and 16-bit vertical resolution.
Based on the traditional DDS technology, it adopts the
innovative TrueArb and EasyPulse technologies, which
overcome the inherent defects of DDS technology in
outputting arbitrary waves and square waves/pulses, and
can provide users with high-fidelity, low-jitter signals. In
addition, the SDG3000X also provides PRBS pattern
generation, sequence, dual pulse, and vector signal
output functions to meet a wider range of application
needs.
Specifications
Bandwidth | 80 MHz , 160 MHz, 200 MHz |
Sample Rate | 1.2 GSa/s (2X Interpolation) |
Channels | 2 |
Vertical resolution | 16 bit |
Arbitrary waveform length | 20 Mpts/ch (40 Mpts/ch Optional) Support sequence |
Display | 7” touch screen |
Interface | Standard: USB Host, USB Device, LAN Optional: GPIB (USB-GPIB adaptor) |
Model | Max Output Frequency | Max Sampling Rate | Vertical Resolution | Waveform Length | Channels | ID |
|---|---|---|---|---|---|---|
SDG3202X | 200 MHz | 1.2 GSa/s | 16-bit | 40 Mpts | 2 | 34c1d90a-dd7b-49ef-8a8d-0c7e047ce623 |
SDG3162X | 160 MHz | 1.2 GSa/s | 16-bit | 40 Mpts | 2 | 685382f5-6c05-46dd-bb00-8443e9e7ebf5 |
SDG3082X | 80 MHz | 1.2 GSa/s | 16-bit | 40 Mpts | 2 | 337ed004-a5a4-4e1c-8fa8-27294afa4a70 |
