Main Features
Frequency up to 13.6 GHz / 20 GHz
0.001 Hz frequency setting resolution
Level setting range: -130 dBm ~ 25 dBm
Phase Noise: -120 dBc / Hz @ 1 GHz, 20 kHz offset (typ.)
Level error ≤ 0.7 dB (typ.)
Provides AM, FM, PM analog modulation with internal, external or Int+Ext source
Single pulse, double pulse and pulse train generator (opt.)
SSG5083A/SSG5085A microwave signal generator’s output frequency range from 9 kHz to 13.6/20 GHz, supports AM & FM & PM modulation, pulse modulation, pulse sequence generator, power meter control and other functions. With standard OCXO reference hardware module inside ensures highprecision and high stability signal output. It is designed for communication, aerospace, national defense and other fields. And it is suitable for various application scenarios such as R&D and production.
Specifications
Frequency range | CW MODE 9 kHz~ 13.6 GHz/20 GHz |
Frequency resolution | 0.001 Hz |
Amplitude Resolution | 0.01 dB |
Phase noise | -120 dBc/Hz offset 20 kHz @1 GHz（typ.） |
Level error | ≤0.7 dB（typ.） |
modulation | AM & FM & PM modulation, pulse modulation, |
Level setting range | -130 dBm~+25 dBm |
Maximum output power | +23 dBm |
other characteristics | Pulse generator，Pulse train generator |
Display | 5 inch capacitance touch screen, RGB (800*480) |
Interface | Standard：USB-HOST, USB DEVICE (USBTMC), LAN (VXI-11,10/100Base，RJ-45)； Option：GPIB |
Model | Frequency Range | Frequency Resolution | I/Q Modulation | Max output power | Phase Noise | Display |
|---|---|---|---|---|---|---|
SSG5083A | 9 kHz ~ 13.6 GHz | 0.001 Hz | No | +23 dB | -120 dBc/Hz @1 GHz, offset 20 kHz (typ.) | 5 inch capacitance touch screen, RGB (800*480) |
SSG5085A | 9 kHz ~ 20 GHz | 0.001 Hz | No | +23 dB | -120 dBc/Hz @1 GHz, offset 20 kHz (typ.) | 5 inch capacitance touch screen, RGB (800*480) |
